SPECIFICATIONS

Brand Name: NoEnName_Null

Certification: CE,RoHS

Choice: yes

Colour Depth: 32 Bit

High-concerned chemical: None

Interface Type: USB

Model Number: X6-800

Novelty: New

Optical Resolution: 600*600

Origin: Mainland China

Product Type: Bar Code Scanner

Scan Breadth: A4

Scan Element Type: CMOS

Scan Speed: 200 scans/second

Scanning: 2D/1D

Scanning Light Source: Natural Light + LED

Signal Connection Type: None

Type: Barcode Scanner

USB cable: 1.5M

Weight: 480g

Product features：

1. Equipped with the new 300,000 global exposure scan engine

2. Larger scanning window for easier reading

3. Adjustable angle, flexible and easy to use

4. Frequently used function buttons, easier to set up

5. 4 styles of prompt sound, soft and bright LED indicator

6. Rich interface, strong compatibility, support a variety of systems and cash registers

Physical parameters

Scan mode: Auto-sensing/continuous scanning

Communication interface: USB-HID keyboard,USB-COM virtual serial port,RS232 serial port

Interface type: USB TYPE-B

Prompt mode: Buzzer,LED light

How it is set up: Press the key to set and manually scan the setting code in turn

Housing material: ABS+PC

Cable standard: Straight line 1.3m

Exterior dimensions: 158 mmx92mmx94mm

Weight: Net weight 335g; Gross weight 345g

Performance parameters

Scan type: CMOS global exposure

Resolution: 640*480

Light source: 617nm red LED

Scan angle: ±60*,±54°, 360* (left and right, front and back, turn).

Scan rate: 120 times/sec

Field of view: 48*(H) x 30* (V)

Printing contrast: Minimum 20%.

Decoding kind:

1D: EAN13,EAN 8,UPC-A,UPC-EO,UPC-E1,Code128,Code39,Code93,

Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodeBar, MSI, RSS-14,

RSS-Ltd, RSS-Exp, Standard 2 of 5, Plessey, ChinaPost 25, GS1 Composite

2D: QR Code, Data Matrix(DM), PDF417,Han Xin,Micro PDF417,Micro

QRCode, MaxiCode, Aztec Code, Code16K, support mobile screen reading

Minimum resolution: 4thousand

Electrical parameters

Input voltage: DC 5V±10%

Current: Working: 240 mAh; Standby:190 mAh

Environment parameters

Temperature: 0°C-50°C(working);-20*C~+70*C(storage).

Humidity: 5%-95% non-condensing
